FEATURES, FUNCTIONS AND SPECIFICATIONS:
• Wide frequency coverage: 9 kHz to 6 GHz, with no interruptions
(Cellular blocked for the US consumer version)
• 45.05 MHz IF DSP (Digital Signal Processing)
• HF direct sampling
• No AGC in the analog processing circuit
• Computer simulated high grade RF frontend
• PC controllable
• 7DDS (Direct Digital Synthesizer) local oscillator
• Accurate reference frequency (0.01 ppm with an optional GPS unit)
• Analog TV reception in both NTSC and PAL formats
• IF analog signal output (45.05 MHz, +/- 7.5 MHz for a total of 15 MHz bandwidth)
• Multi-mode unit capable of receiving AM (Synchronous), ISB, USB, LSB, CW, AIQ (AF-IQ), WFM including FM stereo (optional headphone or stereo speakers required), NFM and P25 (APCO25) digital (optional)
• Composite video output on the rear panel of the unit
• SD card interface
• Selectable IF bandwidths: 200Hz, 500Hz, 1kHz, 3kHz, 6kHz, 15kHz, 30kHz, 100kHz, 200kHz, along with the ability to shift the IF
• CTCSS and DCS selectable squelch functions
• DTMF tone decode
• Built-in voice-inversion descrambling (Not available for the US consumer version)
• CW pitch control, AGC, AFC
• Auto-notch, noise reduction (NR), noise blanker (NB)
• Fast Fourier Transform (FFT) analyzer for fast spectrum display processing
• 12 kHz (analog) I/Q output for DRM® PC receiver
• USB 2.0 interface
• Two antenna ports (Type N)
• Up to 4 antenna ports (Optional antenna switch required)
• 5 VFO’s, 2,000 alphanumeric memories
• Simultaneous monitoring of up to three channels
• Digital Voice Recording (with a SD memory card)
• I/Q output with 0.9 MHz bandwidth (with an optional I/Q unit)
• LAN (Local Area Network) control (with an optional LAN interface)
• P25 (APCO25) decode (conventional mode) (with an optional P25 unit)
• Antenna input level readout (in dBm, dBμ selectable)

SOFTWARE:
AOR Software for various AOR models
3rd Party Software for various AOR Models

PACKING INCLUDES:
1 Pc of Receiver
1 Pc of AC power adapter
1 Pc of Operating manual in English
1 Pc of Control command list
1 Pc of 4GB SD memory card

AVAILABLE ACCESSORIES:
• Standard Control Software = Free to download from AOR website.
• I/Q Software = Only supplied with IQ5001 hardware option
• IQ5001 = I/Q Output Board
•  GPS Antenna Unit
• APCO P-25 Decoder Board
• ARL2300 = Ethernet Controller
• HRE5001 = Rack Mount Kit
• Antenna Switch (But only for receivers with s/n up to 9441000)
• Antenna Switch  (But only for receivers with s/n 09441001 or higher).

Scanner Base
• Digital Signal Processing Architecture
• Frequency Range: 9kHz - 6GHz
• Oustanding signal level correlation on all bands!
• Built-in SD Audio Recorder
